Danuri (a combination of the two Korean words meaning moon and enjoy) is South Korea's first lunar mission.

The objectives are to develop indigenous lunar exploration technologies, demonstrate a 'space internet,' conduct scientific investigations of the lunar environment, topography, and resources, and identify potential landing sites for future missions.

Spacecraft and Subsystems

The spacecraft has a cubic shape with two solar panel wings and a parabolic antenna mounted on a boom. The total mass is 550 kg. Communications are via S-band (telemetry and command) and X-band (payload data downlink). Power (760 W at 28 V) is provided through the solar panel arrays and rechargeable batteries. A monopropulsion system is used, with four 30N orbital maneuver thrusters and four 5N attitude control thrusters.

KPLO is equipped with five science instruments and a Disruption Tolerant Network experiment. The five experiments are a Lunar Terrain Image, a Wide-Angle Polarimetric Camera, a Magnetometer, a Gamma-Ray Spectrometer, and a high-sensitivity camera developed by NASA. Total scientific payload mass is about 40 kg.

LUTI

• Two high-resolution optical cameras (R ~ 5 m)
• To investigate candidate landing sites for Koreas future landing mission

PolCal

• The first polarimetry from lunar orbit
• Twin cameras mounted at 45º tilt angles from the nadir
• Polarimetric measurements at various phase angles up to ~140º
• 430 and 750 nm filters with polarization filters
• Additional 320 nm filter without polarization

KGRS (Gamma Ray Spectrometer)

• Will map spatial distribution of gamma ray energy (10 keV ~ 10 MeV)
• To investigate chemical composition of surface materials

KMAG (MAGnetometer)

• Three tri-axial magnetometers
• Mounted on a 1.2 m long boom

DTNPL (Disruptive Tolerance Network Experiment Payload)

• To conduct an interplanetary internet communication experiment on disruption tolerant networking

Mission Profile

KPLO will launch into a 300 km Earth orbit, followed by a translunar injection burn and a lunar transfer phase, bringing it to the Moon in mid-December. After capture into an elliptical lunar orbit, it will circularize to a 100 km nominal polar orbit, from which it will conduct science operations for approximately one year. If the mission has an extended phase, it will descend to a 70 km orbit or lower.

Courtesy of KARI, KASI

NASA has selected ShadowCam, an instrument developed by investigators at Arizona State University, and Malin Space Science Systems as a U.S. contribution to the Korea Aerospace Research Institute’s first lunar exploration mission. It will reduce risk, increase effectiveness, and improve the designs of future human and robotic missions.

​ShadowCam will map the reflectance within the permanently shadowed regions to search for evidence of frost or ice deposits. The instrument’s optical camera is based on the Lunar Reconnaissance Orbiter Narrow Angle Camera, but is 800 times more sensitive, allowing it to obtain high-resolution, high signal-to-noise imaging of the moon’s permanently shadowed regions.

The instrument will also observe the PSRs monthly to detect seasonal changes and measure the terrain inside the craters, including the distribution of boulders.

Courtesy of NASA

Falcon 9 is a reusable, two-stage rocket designed and manufactured by SpaceX for the reliable and safe transport of people and payloads into Earth orbit and beyond.

Falcon 9 is the world’s first orbital-class reusable rocket.

Stats

Total launches: 395

Total landings: 351

Total reflights: 326

The Falcon 9 has launched 52 humans into orbit since May 2020

Specs

Height: 70 m / 229.6 ft

Diameter: 3.7 m / 12 ft

Mass: 549,054 kg / 1,207,920 lb

Payload to Low Earth Orbit (LEO): 22,800 kg / 50,265 lb

Payload to Geostationary Transfer Orbit (GTO): 8,300 kg / 18,300 lb

Payload to Mars: 4,020 kg / 8,860 lb

On January 24, 2021, Falcon 9 launched the first ride-share mission to Sun Synchronous Orbit. It was delivering a record-setting 143 satellites to space. And while this was an important mission for SpaceX in itself, it was also the moment Falcon 9 overtook United Launch Alliance’s Atlas V for the total number of consecutive successful launches.

SpaceX’s Falcon 9 had become America’s workhorse rocket, launching 31 times in 2021. It has already beaten that record this year, launching almost an average of once a week. While most of the launches deliver Starlink satellites to orbit, the company is still launching the most commercial payloads to orbit, too.

Falcon 9 is a medium-lift launch vehicle, with the capability to launch over 22.8 metric tonnes to low earth orbit. Unlike any other rocket, its first stage lands back on Earth after separating from its second stage. In part, this allows SpaceX to offer the cheapest option for most customers with payloads that need to reach orbit.

Under its ride-share program, a kilogram can be placed in a sun-synchronous orbit for a mere 1.1 million dollars, far cheaper than all other currently operating small satellite launch vehicles.

The reusability and fast booster turnaround times have made Falcon 9 the preferred choice for private companies and government agencies. This has allowed SpaceX to capture a huge portion of the launch market.

Photo courtesy of Jenny Hautmann for Supercluster.

Space Launch Complex 40 (SLC-40) is one of two launch sites leased by SpaceX at Cape Canaveral Space Force Station (CCSFS) in Florida, specifically designed for preparing and launching Falcon 9 rockets. Constructed in the early 1960s, SLC-40 was initially used for 55 Titan III and Titan IV rocket launches, including the Cassini-Huygens mission to Saturn. The pad was active from June 18, 1965, to April 30, 2005.

SpaceX began leasing SLC-40 in 2007, converting it to support Falcon 9 rockets. The pad was first upgraded to accommodate the original version of Falcon 9 and later received another upgrade in 2013 to handle the larger, reusable Falcon 9 rocket. On September 1, 2016, an explosion during a Falcon 9 fueling test caused severe damage to the pad. It was rebuilt rapidly, with construction completed in just 10 months, from mid-February to late November 2017. SLC-40 resumed operations with the successful launch of a Dragon capsule to the International Space Station on December 15, 2017.

After adding a crew access arm to the launch tower, SpaceX launched their first crewed mission from SLC-40 on Saturday, September 28th 2024 for NASA's Crew-9 mission to the International Space Station.

Under SpaceX’s management, SLC-40 has been the site of numerous significant missions. Notable launches include the first all-commercial Dragon mission to the International Space Station, NASA’s DSCOVR mission, the Transiting Exoplanet Survey Satellite (TESS) for NASA and MIT, the first satellite for Turkmenistan, the classified Zuma mission for Northrop Grumman and the U.S. government, the first GPS-III satellite, and the Beresheet lunar lander for Israel. Additionally, in September 2024, SLC-40 will host its first crewed launch with SpaceX’s Crew-9 mission, marking a new milestone for the pad.

Cape Canaveral is a major launch site with four currently active launch pads for Atlas V, Delta IV Heavy, Falcon 9, and Minotaur rockets. Located on Florida’s east coast, it offers extensive access to space for a variety of missions, including those targeting the Space Station, Geostationary Earth Orbit, the Moon, interplanetary destinations, and polar trajectories. The site’s location ensures that launches occur over the open Atlantic Ocean, minimizing risks to populated areas.

Cape Canaveral is often confused with or referred to alongside NASA’s Kennedy Space Center on Merritt Island. While they are separate installations, both play pivotal roles in the U.S. space program. Cape Canaveral has a storied history of significant space missions, including the launch of the first U.S. Earth satellite, Explorer 1, in 1958; the first U.S. astronaut, Alan Shepard, in 1961; the first U.S. astronaut in orbit, John Glenn, in 1962; the launch of the first two-person U.S. spacecraft, Gemini 3, in 1965; and the first U.S. uncrewed lunar landing mission, Surveyor 1, in 1966.

SLC-40 and Cape Canaveral continue to be integral to SpaceX’s ambitious launch schedule and the broader U.S. space program, supporting a wide range of missions and contributing to advancements in space exploration.

Photo courtesy of Jenny Hautmann for Supercluster
